XUANFENG 2/4/6 Heat Pipe Cooler CPU Fan 90mm Air-Cooled Processor Compatible LGA2011-3 X79 X99 E5 2066 115x 1200 1700 I5 AM4 AM5
Choose Intel Core-Xeon
Package: Color Box (CPU cooler*1, Includes 1 set of Intel base bracket and screws,Xeon-x79x99 base bracket+screws * 1 set， silicone grease*2 )
Packing list（Sketch Map）：①②③
Choose AMD Slot:AM4-AM5
Packaging: Color box (CPU cooler * 1, compatible with AM4/AM5 slot base bracket adapter * 1, silicone grease * 1)
Packing list (schematic diagram): ①②③
Compatible with AM4/AM5 slots
Product applicable platform
LGA 2011 2066 2099 E5 X79 X99 2011-3(suitable for computer motherboards with square threaded bases) as shown in the picture
LGA multi-platform universal：
LGA 775/1150/1151/1155/1156/1200/1356/1366/1700/1851/Celer series/Pen series/ Cor Dual i3-i5-i7-i9 12th-14th Gen
3Pin and 4Pin connectors are universally compatible;installation is worry-free regardless of the interface type.
Product image display:
Brand Name：XUANFENG
Fan size: 90 × 90 × 25mm
3Pin speed: 2000 RPM ± 10%
4Pin speed: 800-2000 RPM ± 10%
Fan interface: 3Pin (3-wire constant speed)/4Pin (4-wire temperature control)
Rated voltage: 12V DC
3Pin current: No light 0.18A with light 0.28A ± 10%
4Pin current: No light 0.1A with light 0.2A ± 10%
3Pin power: 2W without light, 3.5W with light ± 10%
4Pin power: 1W without light, 2.5W with light ± 10%
The above data is for one fan, and if it is for multiple fans (air volume, noise, current, power), the data will increase in increments
Statement:
As shown in the figure below, it is an inevitable production process, not a quality problem, nor will it affect the product function and performance. Your successful purchase means that you have approved the process. If there is any dispute or refund due to this process,we will not accept it.
| Brand Name | XUANFENG |
|---|---|
| Cooler Type | Tower |
| High-concerned chemical | none |
| Model Number | XF-900 |
| Power Interface | 3PIN |
| Power Interface | 3pin/4pin |
| Power Interface | 4PIN |
| Origin | Mainland China |
| Blade Quantity | 7 |
| TDP | 135 |
| Supported CPU | LGA 775 |
| Supported CPU | LGA 1150 |
| Supported CPU | LGA 1151 |
| Supported CPU | LGA 1155 |
| Supported CPU | LGA 1156 |
| Supported CPU | LGA1200 |
| Supported CPU | LGA 1356 |
| Supported CPU | LGA 1366 |
| Supported CPU | LGA 1700 |
| Supported CPU | LGA 2011 |
| Supported CPU | LGA 2011-3 |
| Supported CPU | LGA 2066 |
| Supported CPU | Socket AM5 |
| Supported CPU | AM4 |
| Heatpipes | 6 |
| Fan Life | 50000 hrs |
| Air Volume | 60 |
| Bearing | Fluid Bearing |
| Noise | 25dBA |
| Certification | CE |
| Certification | FCC |
| Air Pressure | 2 |
| Lines | 3Pin or 4Pin |
| Fan Size | 90 |
| Series | XF-900 |
| Fan Speed | 800 - 2000 |
| Package | Yes |
| 2 Heat pipes 1FAN TDP: | 90W |
| 4 Heat pipes 1FAN TDP: | 120W |
| 6 Heat pipes 1FAN TDP: | 135W |
| Intel Socket | LGA 775/1150/1151/1155/1156/1200/1700/1356/1366 ( i3 i5 i7 ) |
| For 2011 Socket | LGA2011/2066/2066/ X79 / X99 / x299 / E5 |
| For AMD Socket | AM2/AM2+/AM3/AM3+/FM1/FM2+ |
| For AM4 Socket | AM4 Ryzen3 Ryzen5 |
| Choice | yes |
| semi_Choice | yes |
